Amplifier
- Channels 2
- PSU Transformer Toroidal
- Speaker A / B No
- Speaker Terminals Marantz SPKT-1+
- Number of Terminals 2
- Power Output (8 / 4 Ohm RMS) 60 W / 80 W
- Topology Class A/B
Audio Components and Technologies
- Current Feedback Topology Yes
- HDAM Version SA3, SA2
- High Grade Audio Components Yes
- Customised Components Yes
- Symmetric PCB Layout Yes
- Aluminium Extrusion Heat Sink Yes
- Copper Plated Chassis No
- Marantz Musical Digital Filtering No
- Linear Drive Power Supply Yes
- BI-AMP and Multichannel Option No
- Shottky Diodes Yes
Control
- D-Bus Yes
DAC
- Digital Inputs Coaxial, Optical, USB-A
- Max PCM Sample Rate 192 kHz / 24-bit
- Max DSD Sample Rate DSD 4X (11.2 MHz)
- HDMI 1 ARC
HEOS
- Streaming Technologies Bluetooth, Airplay 2, Roon Ready, Spotify Connect, Tidal Connect
- Streaming Services (subject to change and local availability) Tidal (Hi Res), Deezer (Hi Res), Amazon Music HD, Pandora, TuneIn, iHeartRadio, SoundCloud, SiriusXM, AWA, Mood:Mix, Qplay, Sony HiRes
- HEOS Multiroom and Streaming Yes
- Lossy Formats MP3, WMA, AAC
- Lossless Formats DSD/DSF, FLAC, ALAC, WAV
- Gapless Playback Yes
- HEOS App iOS, Android
Network
- Wi-Fi / Wired LAN Yes / Yes
Other
- Display Low-Noise OLED Monochrome
Preamp
- Phono EQ MM Standard
- Tuner: FM / AM No
- Audio Adjustments Yes
- Power Amp Direct No
- Balanced In / Out No / No
- Preamp Outputs 1
- Subwoofer Output 1 Mono
- Headphone Out Yes
Specifications
- Frequency Response 5 Hz-100 kHz
- Total Harmonic Distortion 0.02 %
- Damping Factor 100<
- Input Sensitivity: MM 1.9 mV / 47 kOhm
- Signal to Noise Ratio: MM/MC 87 dB / -
- Input Sensitivity: High Level 190 mV / 20 kOhm
- Signal to Noise Ratio: High Level 113dB
- Treble Control ± 10 dB at 15kHz
- Bass Control ± 10 dB at 50Hz
- Metal Front Panel Yes
- Power Consumption in W 220
- Standby Consumption in W 0.3
- Auto Power Off Yes
- Detachable Power Cable Yes
- Remote Control RC006PM
- System Remote Function Yes
- Maximum Dimensions (W x D x H) mm 442 x 431 x 129
- Carton Maximum Dimensions (W x D x H) mm 527 x 517 x 255
- Carton Weight (inc. product) in kg 15.5
- Maximum Dimensions (W x D x H) in 17.4 x 17 x 5.1
- Weight in LBS 28.1
- Carton Maximum Dimensions (W x D x H) in 20.8 x 20.4 x 10.1
- Carton Weight (inc. product) in LBS 34.3
