General
- Available Colors: Gold / Silver / Black / Silver-Gold No / No / Yes / Yes
- Carton Maximum Dimensions (W x D x H) in mm 520 x 429 x 243
- Carton Weight (inc. product) in kg 12.3
- CEC Standby Consumption in W 0.5
-
Maximum Dimensions
Antenna:Horizontal:(W x D x H) in mm
Antenna:Vertical :(W x D x H) in mm
W/o Antenna:(W x D x H) in mm 440 x 348 x 161
( 440 x 348 x 231 )
440 x 338 x 161 】 - Metal Front Panel No
- Network Control On Consumption in W 3.7
- Power Consumption in W 650
- Power Consumption No-Sound (ECO on/off) in W 45 W / 75 W
- Pre-Programmed / Learnable / LCD Display No / No / No
- Standby Consumption in W 0.2
- Weight in kg 10.1
HDMI
- DSD Audio Capability No
- HDCP2.3 support Yes
- HDMI: 8K / 4K / CEC / eARC Yes / Yes / Yes / Yes
- HDMI: ALLM / QMS / QFT / VRR Yes / Yes / Yes / Yes
- HDMI: Dolby Vision / HDR 10+ / Dynamic HDR / HLG Yes / Yes / Yes / Yes
- HDMI Inputs: Back / Front 6 / 0
- HDMI max Resolution (8k / 4k) 8k/60 - 4k/120**
- HDMI Outputs: Main / Zone 2 / No
- HDMI Pass-Through in Standby Mode Yes
- HDMI to HDMI Scaling up to 8K 60/50
- Video Conversion Analog -> HDMI Yes
Inputs Outputs
- 7.1 multichannel input No
- Analogue In / Out 4+1 / No
- Bi-amp drive assignable
- Component In / Out 2 / 1
- Composite In / Out 2+1 / 1
- DAB / DAB+ tuner No
- Digital In: Optical / Coaxial 2 / 2
- FM Tuner with RDS Yes
- Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB Yes / Yes / No / No / Yes
- HDMI In / Out 6 / 2
- Multichannel Pre Out Yes (7.2)
- Multi-Room Out: analog / digital 1 / No
- Multi-Room Speaker Terminal assignable
- Multi-Room Video Out: Video / HDMI No / No
- Number of Speaker Terminals 7
- Phono (MM) In Yes
- Speaker A / B assignable
- Speaker Terminal: Gold plated screw / regular screw No / Yes
- Subwoofer Out 2
- USB Audio (Front) / Made for iPod / Made for iPhone® Yes / AirPlay / AirPlay
Multichannel Surround
- Auro 3D No
- Dolby Height Virtualization Yes
- Dolby ProLogic Il / Dolby Surround No / Yes
- Dolby TrueHD / Dolby Atmos Yes / Yes
- DTS HD Master / DTS:X Yes / Yes
- DTS Neo:X / DTS Neural:X No / Yes
- DTS Virtual:X Yes
- DTS:X Pro No
- Front Wide Speakers: Dolby / DTS No
- IMAX Enhanced No
- Max Number of Processing (Preamp) Channels 7.1
- MPEG-H No
- Multichannel Stereo Yes
Multi-Room CI
- DC Trigger Output 1
- HEOS Multi-Room Integrated Yes
- IP Control / RS232 Control / Web Control / App Control Yes / Yes / Yes / Yes
- IR Flasher In Yes
- Main room multichanel audio - Zone stereo downmix Yes
- Marantz Remote Bus Yes
- Multi-Room Zones 2
- TV Sound grouping Yes
- Webbrowser Setup Yes
- Zone Audio Output: Speaker / Preout Yes / Yes
- Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog Yes (2ch) / Yes (2ch) / Yes / Yes
- Zone HDMI Output from HDMI Source No
Network
- AirPlay 2 Yes
- ALAC 192/24 Yes
- Amazon Prime Music* / Pandora* Yes / Yes
- Bluetooth Yes
- Bluetooth Headphone transmission Yes
- Compatible with Remote APP for Smart Phones Android / iOS
- Compatible with Remote APP for Tablets Android / iOS/Amazon Kindle
- DSD Audio Streaming up to DSD5.6
- Ethernet Ports Yes
- FLAC HD 192/24 Yes
- Gapless Playback Yes (FLAC, WAV, ALAC, DSD)
- HEOS Multi-room and Streaming Yes
- Internet radio TuneIn
- Lossless formats FLAC / ALAC / WAV Yes / Yes / Yes
- Lossy formats MP3 / WMA / AAC Yes / Yes / Yes
- Roon Tested Yes
- Spotify Connect* / Tidal* / Deezer* / others * Yes / Yes / Yes / Yes
- WAV 192/24 Yes
- Wi-Fi Yes
Others
- Auto Power off Yes
- Auto Speaker Setup by Microphone Audyssey MultEQ XT
- Bass Sync No
- ECO Mode Yes
- Firmware Update by Network / USB Yes / Yes
- FL Display port hole
- Graphic User Interface - GUI Advanced
- GUI Languages 9
- ISF Certification Yes
- Optimized Bass Redirection Yes
- Setup Assistant Yes
- Sleep Timer Yes
- Smart Select Yes
- Variable Cross Over Yes
- Voice Control - Google Assist / Apple Siri Yes / Yes
- Voice Control - Microphone built-in No
- Voice Control - Works with Amazon Alexa Yes
Sound Enhancements
- Audyssey MultEQ XT
- Audyssey APP Support Yes
- Audyssey Dynamic EQ / Dynamic Volume Yes / Yes
- Audyssey LFC No
- Clock Jitter Reducer No
- Compressed Audio Enhancer: MDAX2 Yes
- Copper Plated Chassis No
- Current Feedback Topology Yes
- Discrete Power Amplifier 7
- Gold plated RCA terminals No
- High Grade Audio Components Yes
- Hyper Dynamic Amplifier Modules (HDAM) Yes
- Power Transformer: Toroidal / EI EI
- Pure Direct Yes
- Single Board Power Amplifier No
- Speaker Setup Presets 2
Specifications
- 70% Guarantee Yes
- Number of poweramps 7
- Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive) 180 W
- Power Output (6 ohm, 1 kHz, 1% 1ch Drive) Yes
- Power Output (8 ohm, 20 Hz - 20 kHz, 0.05% 2ch Drive) 140 W
- Power Output (8 ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive) 100 W
